mysql checkpoint理解

星期二,2011-12-27 at 上午 1:08

在mysql的doc并没有深入介绍checkpoint，本文主要对网上两篇文章阅读加上自己的理解，描述一下transaction log(redo log)和checkpoint之间的关系。
Innodb实现了Fuzzy Checkpoint和Sharp Checkpoint的机制，但在事务日志中，采用了Fuzzy Checkpoint，那何为Fuzzy Checkpoint? Innodb每次取最老的modified page(last checkpoint)对应的LSN,确保此page位置的LSN之前page都已flush到redo log，当mysql crash后，mysql扫描redo log，从last checkpoint开始apply redo log到buffer pool，直到last checkpoint对应的LSN等于Log flushed up to对应的LSN，mysql认为恢复完成。

查看redo log和checkpoint信息：

root@(none) 11:37:27>show engine innodb status \G;







Innodb的checkpoint和redo log有哪些紧密关系？
有几上名词需要解释一下：

Ckp age（动态移动）:最老的dirty page还没有flush到数据文件，即没有做last checkpoint的范围
Buf age（动态移动）:modified page information没有写到log中，但已在log buffer
Buf async（固定点）:日志空间大小的7/8，当buf age移动到Buf async点时，强制把没有写到log中的modified page information开始写入到log中，不阻塞事务
Buf sync（固定点）: 日志空间大小的15/16，当写入很大的，buf age移动非常快，一下子到buf sync的点，阻塞事务，强制把modified page information开始写入到log中。如果不阻塞事务，未做last checkpoint的redo log存在覆盖危险
Ckp async（固定点）: 日志空间大小的31/32，当ckp age到达ckp async，强制做last checkpoint，不阻塞事务
Ckp sync(固定点）:日志空间大小，当ckp age到达ckp sync，强制做last checkpoint，阻塞事务，存在redo log覆盖的危险

接下分析4种情况
1、 如果buf age在buf async和buf sync之间
2、 如果buf age在buf sync之后（当然这种情况是不存在，mysql有保护机制）
3、 如果ckp age在ckp async和ckp sync之间（这种情况是不存在）
4、 如果ckp age在ckp sync之后（这种情况是不存在）

第一种情况：

当写入量巨大时，buf age移动到buf async和buf sync之间，触发写出到log中，mysql把尽量多的log写出，如果写入量减慢，buf age又移回到“图一”状态。如果写入量大于flush log的速度，buf age最终会和buf sync重叠，这时所有的事务都被阻塞，强制将2*(Buf age-Buf async)的脏页刷盘，这时IO会比较繁忙。

第二种情况：

当然这种情况是不可能出现，因为如果出现，redo log存在覆盖的可能，数据就会丢失。buf age会越过log size，buf age的大小可能就超过log size,如果要刷buf age，那么整个log size都不够容纳所有的buf age。

第三种和第四种情况不存在分析：
ckp age始终位于buf age的后面(左边)，因为ckp age是last checkpoint点，总是追赶buf age(将尽可能多的modified page flush到磁盘)，所以buf age肯定是先到达到buf sync。

疑问：ckp async及ckp sync存在意义？

BTW：上周听了褚霸关于OS及mysql分享，收益不少，讲到page cache时候，也提到page cache也存在high water及low water，当dirty page触到low water时，os是开始flush dirty page到磁盘，到high water时，会阻塞一切动作，os会疯狂的flush dirty page，磁盘会很忙，存在IO Storm，如果来避免？就想褚霸说的，innodb其实就是操作系统，只是业务场景不同。Percona的Vadim Tkachenko提出增加类似mid water的点，详细参考(http://www.mysqlperformanceblog.com/2011/04/04/innodb-flushing-theory-and-solutions/)

本文参考：

http://blog.csdn.net/yah99_wolf/article/category/539408

By admin | Posted in 数据库 | Comments (0)

create table as 与binlog

星期二,2011-12-20 at 下午 12:02

使用create table as时，binlog_format不同，存在binlog中的内容也不是一样的。
1、statement与mixed，会和执行语句一样被记录到binlog中
2、row，在binlog会被拆成create table和insert into

mysql> select @@version;
+------------+
| @@version  |
+------------+
| 5.1.56-log |
+------------+
mysql> show variables like '%ignore%';
+-----------------------+-------+
| Variable_name         | Value |
+-----------------------+-------+
| ignore_builtin_innodb | ON    |
+-----------------------+-------+

1、binlog_format:ROW

mysql> flush logs;
mysql>  create table b as select * from a;
Records: 1  Duplicates: 0  Warnings: 0
mysql> flush logs;
[root@dg3 var]# /usr/local/mysql/bin/mysqlbinlog -v -v mysql-bin.000022
SET TIMESTAMP=1321920783/*!*/;
CREATE TABLE `b` (
  `a` int(11) NOT NULL DEFAULT '0',
  `b` varchar(10) DEFAULT NULL
)

BINLOG '
D+nKThMCAAAAKQAAAGkBAAAAAFcAAAAAAAEAAmx4AAFiAAIDDwIUAAI=
D+nKThcCAAAAJQAAAI4BAAAAAFcAAAAAAAEAAv/8AQAAAAJseA==
'/*!*/;
### INSERT INTO lx.b
### SET
###   @1=1 /* INT meta=0 nullable=0 is_null=0 */
###   @2='lx' /* VARSTRING(20) meta=20 nullable=1 is_null=0 */
# at 398

2、binlog_format:MIXED、STATEMENT

[root@dg3 var]# /usr/local/mysql/bin/mysqlbinlog -v -v mysql-bin.000026

SET @@session.lc_time_names=0/*!*/;
SET @@session.collation_database=DEFAULT/*!*/;
create table b1 as select * from a
/*!*/;
# at 201
#111122  8:17:42 server id 2  end_log_pos 244   Rotate to mysql-bin.000027  pos: 4
DELIMITER ;
# End of log file
ROLLBACK /* added by mysqlbinlog */;
/*!50003 SET COMPLETION_TYPE=@OLD_COMPLETION_TYPE*/;
By admin | Posted in 数据库 | Comments (0)

max_seeks_for_key

星期日,2011-12-18 at 下午 12:42

看到max_seeks_for_key让我想到了oracle的optimizer_index_cost_adj，索引扫描与全表扫描成本比较

文档：
Limit the assumed maximum number of seeks when looking up rows based on a key. The MySQL optimizer assumes that no more than this number of key seeks are required when searching for matching rows in a table by scanning an index, regardless of the actual cardinality of the index (see Section 12.7.5.23, “SHOW INDEX Syntax”). By setting this to a low value (say, 100), you can force MySQL to prefer indexes instead of table scans.

但从测试来看，总感觉max_seeks_for_key没起作用

+------------+
| version()  |
+------------+
| 5.1.48-log |
+------------+

root@xx 08:29:28>select count(*),user_id from t group by user_id;
+----------+---------+
| count(*) | user_id |
+----------+---------+
|   445344 |      10 |
+----------+---------+
1 row in set (1.09 sec)

root@xx 08:31:40>show variables like 'max_seeks_for_key';
+-------------------+----------------------+
| Variable_name     | Value                |
+-------------------+----------------------+
| max_seeks_for_key | 18446744073709547520 |
+-------------------+----------------------+
1 row in set (0.00 sec)

root@xx 08:31:55>explain select * from t where user_id=10;
+----+-------------+-------+------+---------------+---------+---------+-------+--------+-------------+
| id | select_type | table | type | possible_keys | key     | key_len | ref   | rows   | Extra       |
+----+-------------+-------+------+---------------+---------+---------+-------+--------+-------------+
|  1 | SIMPLE      | t     | ref  | user_id       | user_id | 9       | const | 213510 | Using where |
+----+-------------+-------+------+---------------+---------+---------+-------+--------+-------------+

root@(none) 08:32:34>set global max_seeks_for_key=1;
Query OK, 0 rows affected (0.00 sec)

root@(none) 08:32:50>show variables like 'max_seeks_for_key';
+-------------------+----------------------+
| Variable_name     | Value                |
+-------------------+----------------------+
| max_seeks_for_key | 18446744073709547520 |
+-------------------+----------------------+
1 row in set (0.00 sec)

root@(none) 08:32:58>exit

root@(none) 08:33:01>show variables like 'max_seeks_for_key';
+-------------------+-------+
| Variable_name     | Value |
+-------------------+-------+
| max_seeks_for_key | 1     |
+-------------------+-------+
1 row in set (0.01 sec)

root@xx 08:33:21>explain select * from t where user_id=10;
+----+-------------+-------+------+---------------+---------+---------+-------+--------+-------------+
| id | select_type | table | type | possible_keys | key     | key_len | ref   | rows   | Extra       |
+----+-------------+-------+------+---------------+---------+---------+-------+--------+-------------+
|  1 | SIMPLE      | t     | ref  | user_id       | user_id | 9       | const | 213510 | Using where |
+----+-------------+-------+------+---------------+---------+---------+-------+--------+-------------+
